AMGO 21004 Width Extension Kit for OHX-10
100% Satisfaction
Guarantee
Authorized
Dealer
Guarantee SAFE Checkout
Adjusts post spacing from 112-1/4 in to 118-1/8 in (2580–3000 mm) to widen the usable span of the OHX-10 overhead two-post lift. Fabricated from high-strength steel to maintain structural rigidity under load. Bolt-on installation interfaces with existing posts using standard fasteners for secure attachment. Expands service capability for wider vehicles and simplifies lift configuration for varied workshop needs.
Specifications
| SKU | 21004 |
| Material | High-strength steel |
| Adjustable width range | 112.25–118.125 in (2580–3000 mm) |
| Compatible models | AMGO OHX-10 Overhead Two-Post Long Lift |
| Installation | Bolt-on extension that mounts to existing posts using standard hardware |
| Package weight (approx.) | 40 lb (18.1 kg) |
| Package dimensions (L×W×H) | 50 × 10 × 8 in (127 × 25.4 × 20.3 cm) |
| Inclusions | Extension rails and mounting fasteners (bolt kit) |
