Katool KT-AC2100 Dual Fully Automatic R-1234YF Recovery, Recycle & Recharge Machine
over $250
100% Satisfaction
Guarantee
Authorized
Dealer
Guarantee SAFE Checkout
High-capacity AC2100 service unit handles R1234YF refrigerant for recovery, recycling and precision charging. The unit operates on 110V AC, 60 Hz and integrates a 1/3 hp oiled hermetic compressor with thermal protection. A dual-stage 3.6 CFM vacuum pump and 7-inch touch display streamline diagnostics, vacuum tests and cycle control. Recovery performance achieves a minimum 95% retrieval in under 30 minutes at standard test temperatures. Charging accuracy holds within ±0.5 ounces for repeatable refrigerant fills and controlled service intervals. Integrated spin-on filter-drier capacity supports heavy contaminant loads without frequent replacement. Hoses conform to SAE J2788 and measure 9.8 feet for flexible reach on most light vehicle systems. Onboard features include a printer, SD database storage and optional heating belt to assist refrigerant handling. Packed for freight with dimensions 22 x 28 x 41 inches and a gross weight of 240 lb for safe transport. Designed for professional shops performing wheel aligner and broader HVAC maintenance where efficient refrigerant management is required.
Features
- Quick Refrigerant Handling: This high-performance machine guarantees minimal downtime, achieving a remarkable 95% recovery rate in under 30 minutes.
- Versatile Compatibility: Service a broad range of vehicles, including electric and hybrid models, offering comprehensive support for various automotive HVAC systems.
- Precision and Ease: Experience precise charging with an accuracy of 0.5 oz (15 g), thanks to advanced loadcell technology for gas and oil measurements.
- User-Friendly Touchscreen: Navigate operations effortlessly with a 7 touch HQ display, ensuring an intuitive and user-friendly process.
- Comprehensive Features: Enjoy additional functionalities such as a built-in printer, optional heating belt, SD database support, vacuum testing, and a robust fan and condenser system, ensuring a thorough and efficient service experience.
Specifications
|
Applicable Refrigerant Type |
R1234YF |
|
Voltage |
110V AC, 60 Hz |
|
Recovery Performance(70-75°F) |
Min.95% in less than 30min |
|
Charge Performance(70-75°F) |
±0.5 oz (15 g) |
|
Operate Temperature Range |
41-122°F (5-50°C) |
|
Max Pressure |
18 bar |
|
Filter-Drier Capacity |
175 lbs (80kg),spin-on type |
|
Gas Loadcell Accuracy |
0.04oz/66lbs(1g/30kg) |
|
Oil Loadcell Accuracy |
0.04oz/66lbs(1g/30kg) |
|
Vacuum Transducer Accuracy |
1 mBar/1000mBar |
|
Recovering Speed |
39.7 lbs/h (18kg/h) |
|
Charge Speed |
2.2 lbs/min(1kg/min) |
|
Hose Length |
9.8’(3m)SAE J2788 |
|
Compressor |
1/3hp(246W).themal protected,oiled,hermetically sealed |
|
Vacuum Pump |
3.6 CFM(120L/min),dual stage |
|
Display |
7”touch HQ |
|
Tank |
0.5 cubic feet(14.3L) |
|
Oil Bottle |
15 cubic inch(250mL) |
Additional information
|
Printer |
YES |
|
Heating Belt |
optional |
|
SD Database |
YES |
|
Vacuum Test |
YES |
|
Fan&Condenser |
YES |
|
Packing Size |
22”x 28”x41”(550x700x1050mm) |
|
Gross Weight |
240lb(110kg) |
Warranty
Katool offers a limited one-year (12 months) warranty on all parts and against all product defects, free of charge.
A 2-year extended warranty plan is available for any Katool or M&E automotive equipment.
Warranty Includes:
- Cylinders, power units, motors, displays, electronics, etc.
- Vehicle lifts include an additional three-year (36 months) warranty on structural components only.
Warranty Conditions:
- Claims must fall within the warranty period.
- Warranty is non-transferable and requires the original order number and purchase from our company or a registered vendor.
- Replacement parts will be provided at no cost, including free shipping.
Note:
- All warranty claims are subject to approval by the warranty/service department.
- Photos and/or videos of defects may be requested.
- Do not disassemble any equipment before the issue is determined.
- Equipment outside the warranty policy will not be covered, and the buyer will be responsible for replacement parts and shipping costs.
- Labor is not included in the warranty.
