Katool KT-H115Z 11,000 lb Two-Post Automotive Lift for Shops
over $250
100% Satisfaction
Guarantee
Authorized
Dealer
Guarantee SAFE Checkout
Heavy-duty 11,000 lb lifting capacity supports light trucks, SUVs and most commercial vehicles. Dual hydraulic chain-drive cylinders and a top-level hydraulic system (220V/60Hz) deliver smooth, consistent lifting performance. Base-plate column design simplifies installation and removes the need for foundation drilling in many garages. Adjustable two-stage front and rear arms provide flexible pick points with 29.5–46 inch and 35.4–58.2 inch reach ranges. Manual dual-side safety lock release and robust column construction maintain secure vehicle support during service. 110.9 inch overall height and 140.4 inch overall width fit commercial bays while offering a 98.4 inch drive-thru clearance. Screw-on pads with +100mm adaptors and rubber door guards protect vehicle finish during lifting and positioning. CE approval and structural testing (115% dynamic / 150% static) provide documented manufacturing standards compliance. Net weight of approximately 1,256.6 lb enables predictable shipping and installation planning. One-year limited parts warranty and a three-year structural warranty cover manufacturing defects and core components.
Specifications
| Lifting Capacity | 11,000 lb (5,000 kg) |
| Max Lifting Height | 70.8 in (1800 mm) |
| Minimum Height | 3.9 in (100 mm) |
| Overall Height | 110.9 in (2818 mm) |
| Overall Width | 140.4 in (3565 mm) |
| Drive-Thru Clearance | 98.4 in (2500 mm) |
| Front Arm Reach | 29.5–46 in (750–1170 mm) — 2 stages |
| Rear Arm Reach | 35.4–58.2 in (900–1480 mm) — 2 stages |
| Motor | 220 VAC / 60 Hz / 1PH / 2.2 kW |
| Net Weight | 1,256.6 lb (570 kg) |
Shipping Coverage
- Freight shipping only within the lower 48 states.
- Fulfillment times are 6-10 business days.
- Free shipping applies to: Tire Changers, Tire Balancers, Shop Tool Equipment, and Scissor Lifts → delivered to commercial addresses or the nearest carrier terminal.
- Two-Post and Four-Post Lifts: Customer must provide a forklift for unloading (if no forklift is available please reach out to customer service as there may be more charges involved). Please make sure to select the correct shipped or pick up option BEFORE ADDING THE ITEM TO YOUR CART. If no forklift is available, we can arrange terminal delivery for pick-up instead.
Additional Services & Fees
- Residential Delivery: $100
- Liftgate Service: $100 (not available for two post, four posts, and select scissor lifts; contact us to confirm before ordering)
Customer Responsibilities
- Customers are responsible for unloading freight from the truck.
- A forklift or unloading dock service is strongly recommended.
- Customers are responsible for any re-delivery fees if the carrier cannot complete delivery.
- Do not sign for damaged or incomplete shipments. Contact Customer Service immediately if items are missing or damaged.
Warranty
Katool offers a limited one-year (12 months) warranty on all parts and against all product defects, free of charge.
A 2-year extended warranty plan is available for any Katool or M&E automotive equipment.
Warranty Includes:
- Cylinders, power units, motors, displays, electronics, etc.
- Vehicle lifts include an additional three-year (36 months) warranty on structural components only.
Warranty Conditions:
- Claims must fall within the warranty period.
- Warranty is non-transferable and requires the original order number and purchase from our company or a registered vendor.
- Replacement parts will be provided at no cost, including free shipping.
Note:
- All warranty claims are subject to approval by the warranty/service department.
- Photos and/or videos of defects may be requested.
- Do not disassemble any equipment before the issue is determined.
- Equipment outside the warranty policy will not be covered, and the buyer will be responsible for replacement parts and shipping costs.
- Labor is not included in the warranty.
